Maxon BMR-CS
Designed for the most demanding gas cylinder delivery applications, Maxon BMR-CS is a heavy-duty elevator designed exclusively for gas cylinder delivery professionals. Thanks to its integrated cylinder retention system and reinforced construction, it meets the industry’s most stringent requirements. With a capacity of up to 1,996 kg (4,400 lb), it ensures safety, performance and reliability in the most demanding working environments.
Key technical features :
- Specially designed for gas cylinders (propane, oxygen, CO₂, etc.).
- Models: BMR-CS35 (1,588 kg/3,500lbs ) / BMR-CS44 (1,996 kg/4,400lbs)
- Integrated handrail and automatic locking
- Galvanized structure as standard for optimum protection against corrosion
- New hydraulic and electrical box mounted on galvanized bracket
- Maximum safety with automatic locking system
- Lifting capacity: 1,588 kg (3,500lbs) to 1,996 kg (4,400lbs)
- Compatible with frame heights from 1,118 to 1,422 mm
Need information or help?
Talk to an STC advisor now
Product documents (Downloadable)
Download the documents you want on Maxon BMR-CS
Full description
Maxon BMR-CS – The specialized elevator for gas cylinder delivery
Maxon’s BMR-CS is a heavy-duty tail elevator designed exclusively for professional gas cylinder deliverers. Thanks to its integrated cylinder retention system and reinforced construction, it meets the industry’s most stringent requirements. With a capacity of up to 1,996 kg (4,400 lb), it ensures safety, performance and reliability in the most demanding working environments.
Ideal for delivering industrial and medical gases
Specially designed to meet the unique challenges of unconventional loading practices, the BMR-CS features :
-
Integrated bottle-holding system
-
Automatic locking mechanism
-
Ergonomic control panel positioned on the column
-
Motorized lowering system on request
-
Sliding inserts or self-centering rollers
-
Galvanized finish as standard for optimum protection against corrosion
Technical specifications
-
Available models: BMR-CS35 (1,588 kg) and BMR-CS44 (1,996 kg)
-
Platform dimensions: 914 x 2032 mm or 1067 x 2032 mm
-
Materials: galvanized steel or lightweight aluminum
-
Compatible frame heights: 1,118 mm to 1,422 mm
-
Integrated aluminum handrail (508 mm)
Designed for maintenance and safety
-
New hydraulic and electrical box mounted on galvanized bracket
-
Accessible main disconnect switch
-
Polyethylene column protection pads
-
Waterproof connectors and protected harnesses
-
Integrated lighting and visibility tape (optional)
Additional options available
-
Manual or auxiliary controls
-
Dual pump/motor
-
Cycle counter
-
Pressure gauge
-
Motorized descent on request
-
Sliding inserts or rollers
Why choose Maxon BMR-CS?
-
Specially designed for gas cylinders (propane, oxygen, CO₂, etc.).
-
Maximum safety with automatic locking system
-
Resistant to extreme conditions thanks to galvanized finish
-
Easy maintenance with front access to hydraulic components
-
Available in Quebec from Solutions Transport Camion
Questions & Answers
What is the difference between BMR-35, BMR-44, BMR-55 and BMR-66?
Here’s a quick comparison of the 2 Maxon BMR-CS Columnlift hatchback models (BMR-CS35 and BMR-CS44).
| Specifications | BMR-CS35 | BMR-CS44 |
|---|---|---|
| Lifting capacity | 1,588 kg (3,500 lb) | 1,996 kg (4,400 lb) |
| Platform material | Galvanized steel or aluminum | Galvanized steel or aluminum |
| Available sizes | 914 x 2 032 mm 1 067 x 2 032 mm |
914 x 2 032 mm 1 067 x 2 032 mm |
| Approximate weight (aluminum) | 760 - 777 kg | 773 - 790 kg |
| Integrated handrail | Yes, aluminum (508 mm) | |
| Compatible frame height | 1,118 mm to 1,422 mm | |
| Motorized lowering system | Available as an option | |
| Anti-corrosion finish | Galvanized - Standard | |
| Bottle retention system | Yes - Integrated | |
What is the lifting capacity of the Maxon BMR-CS?
The BMR ColumnLift is available in 2 versions:
BMR-CS35: 1,588 kg (3,500 lb)
BMR-CS44: 1,996 kg (4,400 lb)
What is the purpose of the Maxon BMR-CS tail elevator?
The BMR-CS is designed specifically for the safe delivery of gas cylinders. It is ideal for distributors of propane, oxygen, CO₂ and medical or industrial gases.
What types of trucks is the Maxon BMR designed for?
The BMR-CS is compatible with trucks with chassis heights between 1,118 mm and 1,422 mm.
